Rexroth A6VM060 71 Series High Speed Hydraulic Piston Motor
Product Introduction: The Rexroth A6VM060 71 series is a high-pressure small-displacement bent-axis variable piston motor, upgraded based on the traditional 65 series. It supports infinite displacement adjustment down to zero, perfectly adapted to closed-circuit hydrostatic transmission systems, and features high speed and compact structure.
Core Advantages: Small size and light weight, ultra-fast response and high rotating speed. It maintains low temperature rise during frequent start-stop operation, excellent high-pressure sealing performance, and longer service life than ordinary series motors, with stable operation for long-term light and medium load working conditions.
Technical Specifications
Displacement: 60cc
Rated Pressure: 450bar
Peak Pressure: 530bar
Structure: 9-piston Bent Axis Variable Structure
Control Type: HA / DA / EP Electric Proportional Control
Installation: SAE Standard Export Flange
Rated Pressure: 450bar
Peak Pressure: 530bar
Structure: 9-piston Bent Axis Variable Structure
Control Type: HA / DA / EP Electric Proportional Control
Installation: SAE Standard Export Flange
Application & Equipment
Widely used for mini excavator travel drive, small drilling rig power system, cotton picker, small crawler agricultural machinery, light hydraulic conveying equipment and small engineering supporting hydraulic devices.
FAQ (A6VM060 71 Series)
Q1: What is the biggest difference between A6VM060 71 series and 65 series?
A: It adopts upgraded high-pressure structure, peak pressure increased to 530bar, stronger pressure resistance and better high-speed stability, more suitable for high-standard export equipment.
A: It adopts upgraded high-pressure structure, peak pressure increased to 530bar, stronger pressure resistance and better high-speed stability, more suitable for high-standard export equipment.
Q2: Can this small-displacement motor run continuously for a long time?
A: Yes, optimized friction pairs reduce heat and abrasion, it can keep stable under long-term light and medium load without power loss.
A: Yes, optimized friction pairs reduce heat and abrasion, it can keep stable under long-term light and medium load without power loss.
Q3: Which pump matches A6VM060 71 perfectly?
A: It is well-matched with Rexroth A4VG71 closed variable pump to form a complete closed hydrostatic drive system.
A: It is well-matched with Rexroth A4VG71 closed variable pump to form a complete closed hydrostatic drive system.
Q4: Does EP control realize full stepless speed regulation?
A: The EP proportional electric control can achieve 0 to full displacement infinite speed adjustment with high precision and quick response.
A: The EP proportional electric control can achieve 0 to full displacement infinite speed adjustment with high precision and quick response.
Q5: What kind of working conditions is this motor fit for?
A: It resists pressure fluctuation well, works steadily on small construction machinery and farm equipment with frequent start and stop.
A: It resists pressure fluctuation well, works steadily on small construction machinery and farm equipment with frequent start and stop.
Q6: Can A6VM060 71 directly replace old 65 version?
A: The SAE flange dimension is different from 65 series. Please check mounting size before replacement and refitting.
A: The SAE flange dimension is different from 65 series. Please check mounting size before replacement and refitting.
